| On/off Detector | |
| High Bay Version | |
| Technical Data | |
| Operating voltage : | 120 ~ 277VAC 50/60Hz |
| Rated load(capacitive load): | 400W @ 120VAC, 800W @ 240VAC, 1000W @ 277VAC |
| Standby power: | < 0.5W |
| Sensitivity: | 10% / 25% / 50% / 75% / 100% |
| Hold-time: | 5s / 30S / 1min / 5min / 10min / 30min |
| Daylight sensor: | 2 ~ 50lux, disable |
| Microwave frequency: | 5.8 GHz +/- 75MHz |
| Transmitting power: | <1mW |
| Detection range: | Max (diameter x height): 16m x 15m |
| Detection angle: | 30° ~ 150° |
| Working temperature: | -20℃ ~ +60℃ |
| IP rating: | IP20 |
| Certificate: | UL ETL FCC |
